Description

Ribcraft 10.5 delivers the ultimate offshore response. By combining Ribcraft’s signature deep V hull and bow sheer with an extended waterline and generous beam this model makes easy work of virtually any sea condition. Designed for extended passages and operations requiring large payload capacities, the 10.5 offers incredible design flexibility. From a simple center console for optimal work space to multiple seating arrangements for crew and passenger transport to cabin arrangements for all weather protection or overnight accommodations, this flagship model answers the needs of virtually any application. Depending on speed and load requirements, the 10.5 offers the choice of twin, triple outboards or twin diesel sterndrives or jets. Ribcraft 10.5 has an cross linked inner matrix construction making her incredibly strong; the layout is to commercial specification. The tubes are bonded to the hull over an extended tube flange that gives them far superior bonding strength between tube and hull than conventional flanges. The end product is an immensely strong hull and tube that meets M.C.A. approval. Maximum Horsepower: 700. Engine: Twin 300hp outboard. Tube Material: Hypalon 1100 Dtx.

Specifications

Accommodation

Maximum number of Persons: 16

Construction

Ribcraft 10.5 delivers the ultimate offshore response. By combining Ribcraft’s signature deep V hull and bow sheer with an extended waterline and generous beam this model makes easy work of virtually any sea condition. Designed for extended passages and operations requiring large payload capacities, the 10.5 offers incredible design flexibility. From a simple center console for optimal work space to multiple seating arrangements for crew and passenger transport to cabin arrangements for all weather protection or overnight accommodations, this flagship model answers the needs of virtually any application.
Depending on speed and load requirements, the 10.5 offers the choice of twin, triple outboards or twin diesel sterndrives or jets.
Ribcraft 10.5 has an cross linked inner matrix construction making her incredibly strong; the layout is to commercial specification. The tubes are bonded to the hull over an extended tube flange that gives them far superior bonding strength between tube and hull than conventional flanges. The end product is an immensely strong hull and tube that meets M.C.A. approval.

Fully customized
Heavy-duty commercial grade construction.
Built to perform in the most inclement of conditions.
Data may vary with changes in specification, weather, elevation & load.
Information is provided as a guideline only.

Internal Length: 9.5m
Internal Beam: 2m
Weight: DOSPEC
Tube Material: Hypalon 1100 Dtx
Tube Diameter: 550mm
Weight: 3000kg approx.

Test Data from Ribcraft 10.5 m Pro
Rpm
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
Speed (Knots)
4.40
6.80
8.90
12.8
20.8
24.2
25.0
26.8
29.5
32.0
37.0
Litres Per Hour
7.90
15.6
20.5
28.9
49.2
58.7
68.3
92.4
128.4
165
202
Litres Per Nautical Mile
1.80
2.29
2.30
2.26
2.37
2.43
2.73
3.45
4.35
5.16
5.9

Engine(s)

Minimum Horsepower: 200
Maximum Horsepower: 700
Engine: Twin 300hp outboard

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
